Processor Family

RISC-V SIMD
RISC_V model execution the NP Benchmark tasks
RISC-V MIMD
Coming Soon
PowerPC
Network processor using a PowerPC. The backplane is a PCIe bus. The Processor, DMA and Switched Ethernet connected to the AXI Bus.
Coldfire
Application of Coldfire in a Electronic Control Unit for a automotive application
RAD750
Implements the ARINC653 Time-Space RTOS running a set of tasks on the basic RAD750 with PCI, 1553B and SpaceWire interfaces.
Renesas SH4
ECU containing a SH4 running safety applications
Nvidia
Drive-PX modeled with a CAN Network that is sending 4 Radar signals and 2 camera signals. The Drive-PX is modeled with the 4 ARM A72, 2 Denver and the GPU
SPARC and LEON
Drive-PX modeled with a CAN Network that is sending 4 Radar signals and 2 camera signals. The Drive-PX is modeled with the 4 ARM A72, 2 Denver and the GPU
Intel ATOM
Modeling a IoT application using an ATOm processor
AMD Opteron
Compares the memory architecture of the Opteron Direct Connect with Xeon Shared Bus
TI OMAP
Uses the OMAP4460 for a camera application

Auto_sh47

Browsable image of the model.

To download OpenWebStart click on the links -
Windows- Compatibility:Windows 10 or higher (*)
macOS - Compatibility:macOS 10.15 (Catalina) or higher (*)
Linux - Compatibility:Ubuntu 18.04 LTS or higher (*)
For an executable version,
Mouse over the icons to view parameters. Click on hierarchy and plotters to reveal content (if provided).
To simulate, click on Launch button, open downloaded file and click Run on the Java Security Page.
